LANNE PRO 筒燈巴疾，整燈精致簡潔，具備精準(zhǔn)的配光肢础，采用SUBROSA 隱光技術(shù)填杀，同時(shí)具有極致的防眩效果模暗。主要適用于酒店及商業(yè)公共空間等場所篱撩。
| Model | Size | Comment | LED Power | Driver | Beam | CCT | Reflector | Finish |
ER2 | 2 2” | F Frame | 08 8W | EL ON-OFF 220V AC Power Supply DL 0-10V Dimming 220V AC Power Supply | 1 15° 2 24° 3 36° 4 48° | 27 2700K 30 3000K 40 4000K | B Black S Specular | WT White |
| Model | Size | Comment | LED Power | Driver | Beam | CCT | Reflector | Finish |
ER2 | 3 3” | F Frame | 13 13W 18 18W | EL ON-OFF 220V AC Power Supply DL 0-10V Dimming 220V AC Power Supply | 1 15° 2 28° 3 38° 4 45° 5 58° | 27 2700K 30 3000K 40 4000K | B Black S Specular | WT White |
| Model | Size | Comment | LED Power | Driver | Beam | CCT | Reflector | Finish |
ER2 | 4 4” | F Frame | 18 18W 25 25W | EL ON-OFF 220V AC Power Supply DL 0-10V Dimming 220V AC Power Supply | 2 20° 3 30° 4 40° 5 50° 6 60° | 27 2700K 30 3000K 40 4000K | B Black S Specular | WT White |
| Model | Size | Comment | LED Power | Driver | Beam | CCT | Reflector | Finish |
ER2 | 5 5” | F Frame | 32 32W 40 40W | EL ON-OFF 220V AC Power Supply DL 0-10V Dimming 220V AC Power Supply | 1 15° 2 24° 3 36° | 27 2700K 30 3000K 40 4000K | B Black S Specular | WT White |
示例：ER25F-32EL-130BWT
